carburettor heat hose route
|
 |
carburettor heat hose route
hose route from C05 to stbd carb: 2020-01-25 Panasonic DMC-FT1
The proposed route of the carburettor heat water hose, from the TEE-piece in hose C05 to the starboard carburettor. Also visible is the original location of the water hose C04, passing down the outside of the engine mount. At this stage, I hadn't yet realised that when the port carburettor air filter was fitted it would foul C04.
|
This page last updated 2020-02-10.
